XFORM 1860 System
Infrastructure
System Details
The XFORM 1860 System offers seamless pipe processing with minimal labor input. Its advanced engineering guarantees precise positioning control and smooth pipe handling, while automating laborious tasks. This innovation ensuring reliable and consistent throughput. Whether processing pipes from 18″ to 60″, the XFORM 1860 System delivers efficiency and scalability for your production needs.
XFORM 1860
Features
- Diameter Range: 18" to 60"
- Pipe Lengths: 10' , 20' & 30'
- Precision Processing for high quality product
- Industry-Leading Safety Standards
- Modular Design
- Flexible Configurations for a variety plant layouts
- Enhanced Throughput
- Seamless End-to-End Integration
- XConnect Compatible
Specifications
| Pipe Size (ID) | Line Speed (ft/min) | 10' Cycle time (s) | 10' Cycle time (min) | 20' Cycle time (s) | 20' Cycle time (min) |
|---|---|---|---|---|---|
| 18" | 5.0 | 120 | 2.0 | 240 | 4.0 |
| 24" | 3.6 | 167 | 2.8 | 333 | 5.5 |
| 30" | 2.4 | 255 | 4.2 | 511 | 8.5 |
| 36" | 2.0 | 300 | 5.0 | 600 | 10.0 |
| 42" | 1.8 | 333 | 5.5 | 667 | 11.1 |
| 48" | 1.5 | 400 | 6.6 | 800 | 13.3 |
| 60" | 1.0 | 600 | 10.0 | 1200 | 20.0 |
